| CUADRO |
Modelo |
C:68X Monocoque Advanced Twin Mold Technology, FSP 4-Link, Boost 148, UDH™ |
|
Juego de dirección |
ACROS Integrated, Top 1 1/8", Bottom 1 1/2", Fiber Inserts for 0.6° Angle Adjustment |
|
Caja de centros |
Shimano BB-MT500PA, 92mm Pressfit |
|
Caño de asiento |
Newmen Advanced, Carbon, 30.9mm |
|
Abrazadera |
CUBE Screwlock 34.9mm |
| SUSPENSIÓN |
Horquilla |
Fox 32 SC Float Performance, 2-Position Remote, Tapered, 15x110mm, 100mm |
|
Amortiguador |
Fox Float DPS Performance Elite Remote, 190x40mm, 2-Position Remote |
|
Montaje Amortiguador |
Delantero: 26x8mm, Trasero: 30x8mm |
| TRANSMISIÓN |
Cadena |
Shimano CN-M6100 |
|
Descarrilador Trasero |
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
|
Descarrilador Delantero |
- |
|
Shifters |
Shimano XT SL-M8100-IR, Direct Attach |
|
Plato palanca |
Shimano XT FC-M8100, 32T, Boost, (175mm - M) (170mm - S) |
|
Piñon |
Shimano XT CS-M8100 10-51T |
| FRENOS |
Freno |
Shimano XT BR-M8100, Hydr. Disc Brake |
|
Rotores |
(180mm/160mm) |
|
Levas de freno |
Shimano XT BR-M8100 |
| COMPONENTES |
Asiento |
Natural Fit Nuance SLT Carbon |
|
Avance |
Newmen Evolution SL 318.2, 31.8mm |
|
Puños |
Natural Fit MTB Performance Lock On |
|
Manillar |
Newmen Advanced 318.0 - Carbon - 740mm |
| RUEDAS |
Maza delantera |
15x110mm |
|
Maza trasera |
12x148mm |
|
Rayos |
28/28H Spokes |
|
Aros |
Newmen Evolution SL X.A.25 Tubeless Ready |
|
Cubiertas Delantera |
Schwalbe Racing Ray, Super Race, Addix Speedgrip, Kevlar, 2.25 |
|
Cubierta Trasera |
Schwalbe Racing Ralph, Super Race, Addix Speedgrip, Kevlar, 2.25 |
| ACCESORIOS |
Pedales |
- |
| PESO |
kg |
|
